| Model |
YR0242 |
YR0242-1 |
| Magnification |
40x~1000x |
| Head |
Sliding Binocular Head, 45° Inclined |
o |
|
| Sliding Binocular Head, 45° Inclined, Anti-Mould System |
|
o |
| Eyepiece |
Wide Field WF10x/18mm |
| Nosepiece |
Quadruple Nosepiece |
| Objective |
Achromatic 4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil) |
| Stage |
Double Layer Mechanical Stage, 140*140mm, Mvoing Range 50*75mm |
| Focusing |
Coaxial Coarse & Fine Focusing. Fine Focusing Scale 0.002mm, Coarse Focusing Stroke 37.7mm/Rotation, With Tension Adjustment, With Up Limit |
| Rubber Cover On Focusing Knob |
|
o |
| Condenser |
N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder |
| Filter |
Blue, Yellow, Green |
| Light Source |
Plan-Concave Mirror |
| Built-in Illumination 6V20W Halogen Lamp, 100~240V |
| YR0242 Biological Microscope Optional Accessories |
| Head |
Sliding Trinocular Head, 45° Inclined, Anti-Mould System |
YR0242-1-op1 |
| Seidentopf Binocular Head, 30° Inclined, Anti-Mould System |
YR0242-1-op2 |
| Seidentopf Trinocular Head, 30° Inclined, Anti-Mould System |
YR0242-1-op3 |
| Eyepiece |
Wide Field Eyepiece P16x/11mm |
YR0242-1-op4 |
| Nosepiece |
Quintuple Nosepiece |
YR0242-1-op5 |
