Nitrogen Tanks
The liquid nitrogen or LN 2 In addition, it is used in dermatological treatments in therapies known as cryotherapy. The term comes from the Greek word "kryo", meaning "cold", so cryotherapy refers to a cold medical treatment, and belongs to the so-called thermotherapies, which have been used by people since antiquity. Dermatologists have applied such therapies since before 1900.
Cryotherapy is a relatively easy procedure to learn and to apply and is characterized by an extremely low complication rate. Generally very good cosmetic and functional results are also obtained. However, as with all other invasive treatment methods, a good knowledge of their function and methodical management, as well as an accurate indication, is a prerequisite for good results.
Types of Nitrogen Tanks a Laboratory May Need
Dryshipper Series for Storege or Transportation (Round Canisters)
- 3 year vacuum warranty
- Cryogenic absorber
- Steam-phase storage
- Insurance
- No LN₂ spills
High Capacity Series for Storege or Transportation (Round Canisters)
- Srong and lightweight aluminium construction
- Heavy duty lockable enclosure offers excellent security
- Numbered index location points for canisters
- Straw storage
- LN dispense pump available
- Roller bases available
- High thermal eff iciency
- 5 year vacuum warranty
- Ultra-low evapouration loss
- Numbered Index Canister Locations
- High Capacity
- High Thermal Eff iciency
- 5 Year Vacuum Warranty
At Kalstein you can find the ideal Nitrogen Tanks
for your Laboratory
There are a myriad of models, so it is normal that you do not know which Nitrogen Tanks
to buy to meet your needs. At Kalstein, we evaluate you to find what you're looking for.
Dryshipper Series for Transportation (Round Canisters) YR05417 // YR05422
Dryshipper Series for Transportation (Round Canisters) is designed for safe sample...
Biomedical Liquid Nitrogen Storage Solutions YR05423 // YR05437
Liquid Nitrogen Supplement Series for LN2 Storage and Supply incorporates the latest innovation, its unique design utilises...
Medical Medium Sized Storage
Series
YR05357 // YR05364
Medium Sized Storage Series (Square Racks) features low LN2 consumption and relatively small footprint...
Medical Medium Sized
Storage Series YR05365 // YR05370
Medium Sized Storage Series (Square Racks) features low LN2 consumption and relatively small footprint for medium capacity...
Our Top Selling Nitrogen Tank
Key Features
- Straw and cryovial storage options
- Rugged and durable aluminium construction
- Designed to ensure no LN₂ spillage
- Vapour phase cryogenic storage
- Faster LN₂ f ill times
- Lockable lids
- 3 year vacuum warranty
Product Advantages
Liquid Nitrogen Adsorption
Adsorbent materials are used to absorb and retain LN₂ for safe transport. No spillover of LN₂ can occur even when the tank is capsized.
| Model | YR05417 | YR05418 | YR05419 | YR05420 | YR05421 |
YR05422 |
|
| Maximum Storage Capacity | No. of Canister | 1 | |||||
| No. of Straws
(0.5ml / EA) |
132 | 374 | 854 | — | |||
| No. of Straws
(0.25ml / EA) |
298 | 837 | 1940 | — | |||
| No. of 2.0 ml Cryovials | — | 100 | 300 | 500 | |||
| No. of Boxes in( 2ml per holder) | — | 4 | 3 | 5 | |||
| Performance | Volume of LN (L) | 3 | 6 | 10 | 15 | 25 | |
| Absorbable Volume of LN2 (L) | 1.3 | 2.9 | 3.4 | 6 | 9 | ||
| Static Evapouration* (L/Day) | 0.16 | 0.2 | 0.43 | 1.5 | 0.89 | ||
| Liquid Phase Static Holding Time**(Day) | 20 | 37 | 23 | 10 | 29 | ||
| Liquid Phase Static Holding Time**(Day) | 8 | 14 | 8 | 4 | 10 | ||
| Dimensions | Opening Diameter (mm) | 50 | 80 | 125 | 216 | 216 | |
| Height (mm) | 435 | 487 | 625 | 540 | 716 | ||
| Outside Diameter (mm) | 223 | 300 | 300 | 394 | 394 | ||
| Canister Outside Diameter (mm) | 38 | 63 | 97 | — | |||
| Outside Height (mm) | 120 | 120 | 120 | — | |||
| Empty Weight (kg) | 3.2 | 4.9 | 6.7 | 8.5 | 15 | ||
| Full Weight (kg) | 4.7 | 7.5 | 11 | 25 | 30 | ||
| Shipping Weight (kg) | 5.5 | 7.7 | 9.7 | 15.2 | 20.5 | ||
| Additional Features | Includes 1 canister
(height 120mm), lockable cap and protective jacket |
Includes 1 canister
(height 120mm), lockable cap and protective jacket |
Includes 1 rack (4 layers),
5*5 cryoboxes, lockable cap and protective jacket |
Includes lockable cap
and protective jacket, no rack |
Includes 1 rack (3
layers), 9*9 cryoboxes and lockable cap, no protective jacket |
Includes 1 rack (5 layers),
9*9 cryoboxes and lockable cap, no protective jacket |
|
Analysis of the best Nitrogen Tanks for your Laboratory
Liquid Nitrogen Tank and sample transport
- Kalstein
Medical practice and research require in some cases, the transport of biological samples, because the samples...
Benefits of Nitrogen Tanks for the Aerospace Sector
- Science
Nitrogen Gas has many applications in the aerospace industry, which employs the highest and strictest quality...
Nitrogen Tanks to Destroy Cancer Cells
- Laboratory
Cryosurgery, sometimes called cryotherapy or cryoablation, is a method of destroying abnormal or diseased...
What Are Liquid Nitrogen Tanks And What Are They Used For In A Laboratory?
Liquid Nitrogen Tanks are units used for the conservation of Laboratory samples at very low temperatures. Due to fast...
Catalog of models of Nitrogen Tanks on offer
-
Biomedical Liquid Nitrogen Storage Solutions Dryshipper Series for Transportation (Round Canisters) YR05417 // YR05422
Select options This product has multiple variants. The options may be chosen on the product page -
Biomedical Liquid Nitrogen Storage Solutions YR05423 // YR05437
Select options This product has multiple variants. The options may be chosen on the product page -
High Capacity Series for Storage or Transport (Round Canisters) YR05383 // YR05392
Select options This product has multiple variants. The options may be chosen on the product page -
High Capacity Series for Storage or Transport (Round Canisters) YR05393 // YR05402
Select options This product has multiple variants. The options may be chosen on the product page -
High Capacity Series for Storage or Transport (Round Canisters) YR05403 // YR05416
Select options This product has multiple variants. The options may be chosen on the product page -
Medical Medium Sized Storage Series YR05357 // YR05364
Select options This product has multiple variants. The options may be chosen on the product page -
Medical Medium Sized Storage Series YR05365 // YR05370
Select options This product has multiple variants. The options may be chosen on the product page -
Small Sized Storage Series (Square Racks) YR05371 // YR05382
Select options This product has multiple variants. The options may be chosen on the product page
UPDATED KALSTEIN
Guides to becoming an expert in Nitrogen Tanks
Nitrogen Tank equipment are essential products in a Laboratory, we provide guides and recommendations
for better use, so you can work as an expert.
Importance of Nitrogen Tanks
- Kalstein
There are now many products that contain gases or use gases for their production, so it is necessary to store these...
Nitrogen Tanks and artificial insemination?
Nitrogen Tanks are essential equipment for the application of the artificial insemination (AI) technique, since they
Use of Nitrogen Tanks for the Wine Sector
Wine is a beverage that is associated with the history of mankind, since archeologists have found evidence...
How are Nitrogen Tanks used for food preservation?
The preservation of food is a key stage in the production and consumption chain, since it prolongs the shelf life of the food, while ensuring that they reach the consumer in optimal conditions. This is essential, since the physicochemical, microbiological and organoleptic characteristics of the product are maintained from its production, storage, transfer, distribution and sale to the public...
Frequently Asked Questions about Nitrogen Tanks from our customers
How do you know the prices of the Nitrogen Tanks?
To know the price of Nitrogen Tanks we invite you to send us an email with your request through the contact form.
What are the delivery times of the Nitrogen Tanks?
The delivery time of your Kalstein product it will depend on the following:
- If the equipment of your interest is in stock or if otherwise it must be manufactured.
- The type of freight you have chosen may be; air or sea.
- Equipment in stock:
- Delivery Time ( Aerial ): 15 -30 days .
- Delivery Time ( Maritime ): 45-60 days .
- Equipment not in stock:
- Delivery Time ( Aerial ): 30 -60 days .
- Delivery Time ( Maritime ): 60-90 days .
How to make a purchase of Nitrogen Tanks ?
- By email: [email protected]
- By telephone: +33 (0) 1 78 95 87 02
- E-commerce: Via Kalstein's official website in your country.
How does the warranty work?
All Kalstein equipment has a 1-year warranty against manufacturing defects. The warranty does not cover damage caused by poor installation or operation by the user, transport defects or by uses other than those specified by the manufacturer. Warranty excludes electrical or consumable parts. For more information visit our “Terms and Conditions ” by clicking HERE
At Kalstein, we provide our customers with induction and technical support through new online methods. You can visit our induction videos, technical assistance and guidance provided by a Kalstein team through our channel Youtube (Kalstein English). HERE
Can I request an online quote?
Of course, you can ask for a quote by the Kalstein team of your interest, directly from our website official. U Once you have identified the model of your preference, make click HERE
