Description
- 15 ′ LED display with multilingual function
- CF + B model simultaneously, PDI, DPDI, TDI, TSI, supports trapezoidal imaging, virtual convex matrix and convex matrix expansion.
- Anatomy M, Color M mode
- Pressure rating
- Complex model image
- Automatic IMT measurement, automatic endometrial measurement, automatic quality assessment
- Duplex and triplex PW can be switched freely
- PW auto-tracking measurements
- Multiple birth measurements
- Built-in DICIM 3.0 protocol, can print and send via DICOM 3.0
- Integrated workstations, databases, imaging reports, fetal development curves, scoring standards, etc. can be inserted.
- Online care function, instruct the user how to operate in the next step.
- The printed area is adjustable, which can be images, reports, or images + reports, etc.
- User rights control, password can be set.
Technical description
| Model | YR05148 | |
| Picture Modes | B, 2B, 4B, M, B / M, B / C, B / D, B / C / D , B / CFM / D, PDI Color, Dual Color, Simultaneous 2D / Composite Color, PW, Duplex / Triplex, CFM, CDE, PD, Directional PD, CD |
|
| Physical specifications | ||
| Team Size | 375mm * 360mm * 75mm | |
| Equipment Weight | 3.5 kg | |
| Packing size | 490mm × 270mm × 490mm | |
| Packaging Weight | 10kg | |
| Connectivity / Media / Peripherals | ||
| Transducer Ports | two | |
| USB ports | two | |
| HDD | 64GB (SSD), 120G / 200GB SSD (optional) | |
| Printing area | Image, report, Image + report | |
| Ethernet port | 2 (100Mb / 1000Mb) | |
| External display | VGA, HDMI, etc .. | |
| Printer (Optional) | USB Printer, Digital Laser Printer, B / W Digital Thermal Printer |
|
| Digital technology | Panoramic imaging technology Fully digital signal processing technology Multi-beamforming technology Spot reduction technology Tissue harmonic imaging technology Dynamic tissue optimization technology Duplex and triplex synchronous display Directional power Doppler imaging parameters Imaging parameters special tissue presets PW Online Auto Trace Update CF + B mode on one screen Complex model imaging Automatic IMT measurements Virtual convex matrix Trapezoidal imaging |
|
| General performance | Digital broadband | 12288 channels |
| Beam former | reprogrammable | |
| Transmission voltage | Adjustable (15 steps) | |
| Beamformer frequency range | 1 ~ 40 MHz | |
