Description
- 96-way manifold, automatic and manual positioning.
- Super washing speed for whole microwell plate.
- Multi-channel, 3 for wash, 1 for rinse and 1 for waste.
- High presicion volume dispensing.
- Low residual volume.
- Plate shaking function, time and speed adjustable.
- Large memory for protocol storage.
- User-friendly operation system, large LCD display.
Technical Specifications
| Model | YR05126 |
| Plate Mode | 96-well plate or strip |
| Residual Volume | <1ul |
| Washing Volume | 50~3000ul/well, 10/50l continuously adjustable |
| Washing Cycle | Up to 99 cycles |
| Strip Washing | Wash 2 plates at a time, 1-8 strips programmable |
| Soaking Time | 0~24hours |
| Shaking Time | 0~24hours |
| Display | Large LCD |
| Wash Channels | 5 channels, 3 for wash, 1 for rinse and 1 for waste |
| Memory | 100 washing protocols & 10 plate protocols |
| Interface | RS-232 |
| Power Requirement | AC 110/220V±10%, 50±1 HZ |
| Net Weight | 23.8 Kg |
| Dimension L×W«H(mm). | 610×460×240 |
