Colorimeter
Type of Colorimeter that a Laboratory may need
Spectrocolorimeter
In Kalstein you can find the ideal Colorimeter for your Laboratory
High cost-effective Portable Colorimeter YR05515
Kalstein team concentrates on customer needs and develops a new serie YR05515 with high precision & low cost & two apertures...
Precision Colorimeter YR05509
Kalstein team concentrates on customer needs and develops a new serie YR05509 // YR05513 with high precision & low cost...
Precision Colorimeter YR05506 // YR05508
YR05506 // YR05508 precision colorimeter features with 8/d structure that is very precise. 8mm measurement aperture makes...
Precision Colorimeter YR05510
Kalstein team concentrates on customer needs and develops a new serie YR05509 // YR05513 with high precision & low cost...
Our best-selling Colorimeter
Product Advantages
- Built-in white plate parameters. No need to calibrate each time which realize rapid measurement.
- Double Apertures: Φ8mm flat aperture and Φ4mm tip aperture for switch, easy to measure concave sample in large plane.
- Equipped with rechargeable built-in high-capacity Li-ion battery. No need to purchase battery repeatedly.
- Handheld design: small and convenient; make the measurement easier.
- Exquisite appearance: adopts traditional and fashionable aesthetic designs.
- High cost performance: large output, good quality, cheap products.
Model | YR05513 |
Illuminating/Viewing Geometry | 8/d(8°illumination angle/diffuse viewing); Conforms to CIE No.15,GB/T 3978. |
Illumination | LED white light |
Detector | Silicon photoelectric diode |
Measuring Aperture | Φ8mm flat aperture; Φ4mm tip aperture |
Color Space | CIE LAB |
Color Difference Formula | ΔE*ab |
Observer Angle | CIE 10° |
Light Source | D65 |
Displayed Data | Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset |
Measuring Time | 1.0s |
Repeatability | Standard deviation within ΔE*ab 0.03 (Average of 30 measurements of standard white plate) |
Errors Between Each Equipment | Within ΔE*ab 0.4 |
(Average for 12 BCRA Series II color tiles) | |
Dimension | 205×67×80 mm |
Weight | 500g |
Power source | Rechargeable lithium-ion battery 3.7V@3200mAh |
Lamp Life | TFT 2.8 inch |
Interface | USB |
Data Memory | 100pcs standards 10000pcs samples |
Operating Environment | 0~40℃(32~104°F) |
Storage Environment | -20~50℃(-4~122°F) |
PC Software | No |
Standard Accessory | Power Adapter, User Guide, Wristbands, Φ8mm flat aperture; Φ4mm tip aperture. |
Optional Accessory | Micro Printer, powder test box |
Notes: The specifications are subject to change without notice. |
Analysis of the best Colorimeters for your Laboratory
Colorimeter for Water Analysis
The colorimeter is an instrument used to measure the color of a substance, using the RGB...
Colorimeter in scientific research
The Colorimeter is a very sensitive measuring tool used in scientific research to determine the content of a substance in a sample...
Applications of the Colorimeter
The colorimeter is a valuable tool for the diagnosis of genitourinary diseases in animals...
Use of the Colorimeter in determining
A Colorimeter is a tool used to determine the concentration of a chemical in a sample. It is a portable and compact device ...
Catalog of Colorimeters models on offer
Guides to become an expert in Colorimeter
Determination of the refractive index of a sample using a Colorimeterr?
A Colorimeter is a device used to measure the intensity of a color. It can be used to measure ...
What are the sensors used by a Colorimeter? - Kalstein
At Kalstein we have the ideal equipment used to measure the color of a liquid, gas or ...
What is a
Colorimeter? - Kalstein - Laboratory
A Colorimeter is a device used to measure and analyze colors. Currently, thanks to technological...
Differences between Spectrocolorimeters and Colorimeters
Today colors play a fundamental role in our lives. However, unlike other parameters such as weight or length, there is no physical scaleFrequently Asked Questions about Colorimeter
