Description
- YR06233 electro-hydraulic operating table is made specially to meet demand of general surgical operations.
- It adopts full 304 stainless steel. Tabletop is X-ray available.
- Auto-lock on remote control, electric base lock and release.
Technical Specifications
| Model | YR06233 |
| Length/width | 2000mm/500mm |
| Elevation(up/down) | 690mm/1100mm |
| Trendelenburg | 30° |
| Reverse Trendelenburg | 30° |
| Lateral Tilt(left/right) | 18°/18° |
| Head Rest(up/down) | 40°/90° |
| Footplate(up/down&horizontal positioning) | 15°/90°/90° |
| Back plate(up/down) | 90°/40° |
| Longitudinal Sliding | 350mm |
| Power | 220v,50Hz, 1.0kW |
