Description
The Compteur de Conductivité/DO de Paillasse YR06384 is an innovative instrument designed to provide exceptional precision and ease of use in measuring conductivity and dissolved oxygen. Equipped with a 7-inch capacitive color touchscreen, it ensures high resolution and sensitivity for intuitive operation. This device includes intelligent features such as automatic calibration, data storage, and Bluetooth connectivity for wireless printing and PC connection. With a data storage capacity of 1000 test sets, it facilitates data transfer and analysis in Excel. Suitable for diverse measurement needs, this device is an excellent choice for professionals seeking precise results in the laboratory.
Market Price
In the market, conductivity and DO meters like the YR06384 typically range from $1,200 to $2,000. This competitive pricing reflects the advanced features and reliability of the device, guaranteeing excellent value for money. To know the exact price and receive a personalized quote, we invite you to use our Kalstein Plus platform to generate an automatic quotation.
Frequently Asked Questions
Q: Is this product easy to use for beginners?
A: Yes, the intuitive touchscreen and automated functions make this device very simple to use even for beginners.
Q: Can I transfer data to other devices?
A: Absolutely, the meter features data transfer options via USB and Bluetooth.
Q: Does the electrode need frequent replacement?
A: With proper maintenance, the electrode can last a long time before requiring replacement.
Pros and Cons
Pros: Ease of use, high precision, advanced connectivity, large storage.
Cons: May require a larger budget, initial training for advanced settings optimization.
Product Use in the Field
The YR06384 meter is primarily used in environmental laboratories, water treatment facilities, and chemical industries to monitor conductivity and dissolved oxygen. Its ability to switch between different modes (conductivity, TDS, salinity, resistivity) allows for exceptional adaptability in various practical applications. Users can thus obtain reliable and precise measurements necessary to ensure the quality of analytical and environmental processes.
Recommendations
To ensure optimal performance, it is recommended to calibrate the device regularly and ensure that electrodes are clean and in good condition. Updating the integrated software via available updates will also be helpful to fully exploit the device’s features. If in doubt, consult the provided user manual for detailed instructions.
Features
- 7-inch high-resolution capacitive color touchscreen.
- Automatic calibration, temperature compensation, and data storage.
- USB, RS232, and Bluetooth connectivity options.
- Support for wireless printing.
- Smart display of electrode status.
Technical Specifications
Model | YR06384 | |
Cond.
|
Measuring Range
|
Conductivity: |
(0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
(200~2000)μS/cm, (2.00~20.00)mS/cm | ||
(20.0~200.0)mS/cm, | ||
(200~2000)mS/cm (K=10) | ||
TDS: (0 ~ 100)g/L | ||
Salinity: (0 ~ 100)ppt | ||
Resistivity: (0 ~ 100)MΩ·cm | ||
Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
Temp. Compensation Range | (0 ~ 50)ºC, auto | |
Electrode Constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
Reference Temp. | 25ºC, 20ºC, 18ºC | |
DO
|
Measuring Range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
Response Time | ≤30s (25ºC, 90% response) | |
Residual Current | ≤0.1 mg/L | |
Temp Compensation | (0 ~ 45)ºC, auto | |
Salinity Compensation | (0 ~ 45) ppt, auto | |
Pressure Compensation | (80 ~ 105) kPa, auto | |
Auto Calibration | Air saturated by water; water saturated by air | |
Electrode Type | Polarographic | |
Temp.
|
Range | (-10 ~ 110)ºC |
Resolution | 0.1ºC | |
Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
Other
|
Display | 7-inch colored capacitive touch screen |
Data Storage | 1000 sets | |
Power | 12V/1A | |
Output | USB, RS232, Bluetooth | |
Ambient Temp. | 15 ~ 30 ºC | |
Ambient Humidity | ≤85% | |
IP Grade | IP54 | |
Dimensions/N.W. | 240×170×70mm/600g | |
Shipping Size/G.W. | 470x430x85mm/2.6kg |
