YR06828 Class B benchtop pulsating vacuum autoclave

Features and Specifications:

• Volume: 80L
• Design pressure: -0.1/0.3 MPa
• Operating temperature: 105-134°C
• Sterilization time: 0-99 min
• Power: 2 KW
• Vacuum system: Pre-vacuum, post-vacuum
• Screen: 7.0-inch LCD
• Camera material: AISI304 stainless steel
• Steam generator: Built-in, 304 stainless steel
• Safety alarm: Several alarms to ensure safe operation, such as over-temperature alarm, over-pressure alarm, lack of water alarm and anti-drying of the steam generator.

The YR06828 Autoclave stands out not only for its excellent technical specifications but also for its ease of use, thanks to its intuitive display and alarm system that ensures trouble-free operation. This unit is perfect for medium-sized laboratories and hospitals that require reliable and efficient sterilization equipment.

Frequently Asked Questions:

1. What types of materials can I sterilize with the YR06828?The YR06828 autoclave is suitable for sterilizing a wide variety of materials, including textiles, solids, liquids, rubber, instruments, and glassware, through preset and customizable cycles.
2. Is the YR06828 Autoclave easy to operate?Yes, the YR06828 features a 7.0-inch LCD screen that allows you to monitor the sterilization process, and a microprocessor control for easy operation.
3. How do I maintain the YR06828?It is recommended to regularly check and clean the chamber and steam generator, as well as verify the water level and drying function after each cycle.

Advantages and Disadvantages:

Advantages:

• High efficiency: Its pulsating vacuum design ensures fast and effective sterilization.
• Enhanced safety: Multiple safety alarms, such as over-temperature and over-pressure alarms, protect both the equipment and the user.
• Easy to operate: The LCD screen and intuitive controls make managing sterilization cycles easy.
• Versatility: The YR06828 is ideal for a variety of applications, including clinics, laboratories, and hospitals.

Disadvantages:

• Chamber size: Although it has a volume of 80L, it may not be suitable for larger capacity installations.
• Requires regular maintenance: Like any sterilization equipment, the YR06828 requires regular maintenance and cleaning to ensure optimal performance.

Product Use in the Field

The YR06828 Class B Pulsed Vacuum Autoclave is an essential tool in medical and laboratory settings. In hospitals and clinics, it is used to sterilize surgical instruments, textiles, and essential laboratory equipment. Furthermore, in research laboratories, it is indispensable for ensuring the sterilization of sensitive materials and guaranteeing safe sample handling. Its pre-vacuum and post-vacuum system optimizes the process, eliminating any trace of air, thus ensuring thorough and effective sterilization, even of porous and packaged materials.

Recommendations

To maximize the performance and durability of the YR06828 Autoclave , make sure to:

• Regularly check alarms and safety controls to prevent damage to equipment and ensure safety during operation.
• Perform regular maintenance on the steam generator and vacuum pump to ensure efficient operation.
• Use only distilled or demineralized water to avoid damage from mineral buildup in the steam generator.
• Follow the instructions in the manual for temperature calibration and cycles, ensuring that they are properly adjusted to the different materials being sterilized.

Technical Specifications
