Handheld Color Spectrophotometer YR05496
Handheld Color Spectrophotometer YR05496 — équipement de laboratoire Kalstein avec spécifications techniques, caractéristiques avancées et solutions professionnelles certifiées pour usage scientifique.
The Handheld Color Spectrophotometer YR05496 is a cutting-edge tool designed to deliver exceptional accuracy in color management and matching, catering to diverse industries. Weighing just 600 grams, this portable spectrophotometer adheres to international standards like CIE No.15 and GB/T 3978, utilizing a 45/0 geometric optical structure. Its wavelength range of 400 to 700 nm and 8 mm aperture ensure supreme precision in color measurements, achieving a DeltaE*ab accuracy index of 0.04. It features an ergonomic design with a 3.5-inch touchscreen, which simplifies its use across sectors such as plastics, paints, textiles, food, and cosmetics. Enhanced by the SQC8 color management software, the YR05496 offers advanced functionality when connected to a PC, strengthening your quality control processes comprehensively and efficiently.
Market Price
The YR05496 spectrophotometer offers excellent value for businesses aiming to optimize their color quality control procedures, with a market price range between $33,500 and $33,800 USD. This investment is validated by its vast storage ability of up to 10,000 samples and its adaptability across both industrial and laboratory applications. To experience a seamless purchasing process, request a personalized quote or generate one instantly via Kalstein Plus.
Frequently Asked Questions
- What applications are ideal for the YR05496?
The spectrophotometer is ideal for sectors such as plastics, paints, textiles, and also for analyzing fluorescent samples and food products. - Is the device PC compatible?
Yes, the YR05496 includes color management software that facilitates direct PC connections for more efficient and comprehensive data management. - How much data can it store?
This model boasts a significant storage capacity, accommodating up to 1,000 standards and 10,000 samples, tailored for detailed data recordings.
Advantages and Disadvantages
The YR05496's primary advantages include its remarkable accuracy (ΔE*ab of 0.04), a user-friendly portable design, and adherence to multiple international colorimetry standards. Its USB and RS232 connectivity ensure effortless data transfer to other devices. A potential downside is its confinement to the visible wavelength range (400-700 nm), which might not suffice for applications necessitating a broader spectrum.
Field Applications
The YR05496 excels in quality control, particularly in the production of plastics, paints, and textiles, where maintaining color consistency is crucial. Its portability and accuracy make it perfect for on-site production measurements or laboratory use, providing precise results almost instantly. Thanks to its advanced color management software, it supports real-time evaluation, ensuring product quality consistently.
Recommendations
To ensure optimal performance, the YR05496 should undergo regular calibrations and be stored in a clean, dust-free environment. Its lithium-ion battery supports up to 5,000 measurements over 8 hours, necessitating regular recharging to maintain readiness. For a personalized quote or to generate one swiftly, visit Kalstein Plus and discover how the Portable Color Spectrophotometer YR05496 can elevate color control accuracy and efficiency in your industry.
Features
- Advanced 45/0 geometric optical structure
- Compatibility with multiple colorimetric standards
- Portable design with a large touchscreen interface
- SQC8 software for enhanced PC integration
- High storage capacity for extensive data logging
- Capable of real-time color evaluation and data management
Technical Specifications
| Model | YR05496 |
| Illumination/observation system | 45/0 method (45 ring-shaped illumination, vertical viewing) Comply with CIE No.15，GB/T 3978. |
| Integrating sphere Size | Φ58mm |
| Light Source | combined LED sources |
| Sensor | Silicon photodiodearray |
| Wavelength range | 400~700nm |
| Wavelength pitch | 10nm |
| Reflectance range | 0~100% |
| Measuring Aperture | Φ8mm |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV |
| Color difference Formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00 |
| Other Chromaticity Data | Whiteness – WI(ASTM E313，CIE/ISO,AATCC,Hunter)， Yellowness-YI(ASTM D1925，ASTM 313), TI(ASTM E313，CIE/ISO), Metamerism Index (Mt) Colour Stain, Color Fastness, Color Strength, Opacity |
| Observer | 2°/10° |
| Illuminant | D65,A,C,D50,D55,D75,F2,F6,F7,F8,F10,F11,F12 |
| Display Data | Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation |
| Measurement Time | 1.5s |
| Repeatability | Spectral Reflectance: standard deviation within 0.1%(400~700nm: within 0.2%) Colorimetric Value: Standard deviation within DeltaE*ab 0.04 (Measurement conditions: white calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.) |
| Inter Instrument Agreement | Within DeltaE*ab 0.2 (Average for 12 BCRA Series II color tiles) |
| Dimension | L*W*H=90*77*230mm |
| Weight | 600g |
| Battery | Li-ion battery. 5000 times within 8 hours. |
| Lamp Life | 5 years, more than 1.6 million measurements |
| Display Screen | TFT 3.5inch, Capacitive Touch Screen |
| Interface | USB/RS-232 |
| Data Memory | 1000 Standards, 10000 Samples |
| Operating Temperature | 0~40℃(32~104°F) |
| Storage temperature | -20~50℃(-4~122°F) |
| Standard Accessory | Power Adapter, Li-ion Battery, Operating Instruction, CD-ROM (containing management software), Data Line, White and Black Calibration Cavity, Protective Cover and Wrist Strap |
| Optional Accessory | Micro Printer, Powder Test Box |
| Notes | The specifications are subject to change without notice. |
Spécifications techniques
| Dimensions | L 34 × W 13 × H 29 cm |
|---|---|
| Poids | 3 kg |
| Fabricant | Kalstein |
